yep, it does vary because with the hdr10plus to DV remux of WW84, the imax scenes play incorrectly in 276/277 on my C8 internal player.
the original dual-layer file (the p8 too) play correctly in 66/66
it plays perfectly in 66/66 and switches to 276/277 without issues on my bluray player x700. surely because l5 metadata are useless to bluray players. shield is fine too
hdr10plus to DV RPU:
Code: Select all
Parsing RPU file...
{
"dovi_profile": 8,
"header": {
"rpu_nal_prefix": 25,
"rpu_type": 2,
"rpu_format": 18,
"vdr_rpu_profile": 1,
"vdr_rpu_level": 0,
"vdr_seq_info_present_flag": true,
"chroma_resampling_explicit_filter_flag": false,
"coefficient_data_type": 0,
"coefficient_log2_denom": 23,
"vdr_rpu_normalized_idc": 1,
"bl_video_full_range_flag": false,
"bl_bit_depth_minus8": 2,
"el_bit_depth_minus8": 2,
"vdr_bit_depth_minus_8": 4,
"spatial_resampling_filter_flag": false,
"reserved_zero_3bits": 0,
"el_spatial_resampling_filter_flag": false,
"disable_residual_flag": true,
"vdr_dm_metadata_present_flag": true,
"use_prev_vdr_rpu_flag": false,
"prev_vdr_rpu_id": 0,
"vdr_rpu_id": 0,
"mapping_color_space": 0,
"mapping_chroma_format_idc": 0,
"num_pivots_minus_2": [
0,
0,
0
],
"pred_pivot_value": [
[
0,
1023
],
[
0,
1023
],
[
0,
1023
]
],
"nlq_method_idc": null,
"nlq_num_pivots_minus2": null,
"num_x_partitions_minus1": 0,
"num_y_partitions_minus1": 0
},
"vdr_rpu_data": {
"mapping_idc": [
[
0
],
[
0
],
[
0
]
],
"mapping_param_pred_flag": [
[
false
],
[
false
],
[
false
]
],
"num_mapping_param_predictors": [
[
0
],
[
0
],
[
0
]
],
"diff_pred_part_idx_mapping_minus1": [
[
0
],
[
0
],
[
0
]
],
"poly_order_minus1": [
[
0
],
[
0
],
[
0
]
],
"linear_interp_flag": [
[
false
],
[
false
],
[
false
]
],
"pred_linear_interp_value_int": [
[
0
],
[
0
],
[
0
]
],
"pred_linear_interp_value": [
[
0
],
[
0
],
[
0
]
],
"poly_coef_int": [
[
[
0,
1
]
],
[
[
0,
1
]
],
[
[
0,
1
]
]
],
"poly_coef": [
[
[
0,
1
]
],
[
[
0,
1
]
],
[
[
0,
1
]
]
],
"mmr_order_minus1": [
[
0
],
[
0
],
[
0
]
],
"mmr_constant_int": [
[
0
],
[
0
],
[
0
]
],
"mmr_constant": [
[
0
],
[
0
],
[
0
]
],
"mmr_coef_int": [
[
[]
],
[
[]
],
[
[]
]
],
"mmr_coef": [
[
[]
],
[
[]
],
[
[]
]
]
},
"nlq_data": null,
"vdr_dm_data": {
"affected_dm_metadata_id": 0,
"current_dm_metadata_id": 0,
"scene_refresh_flag": 1,
"ycc_to_rgb_coef0": 9574,
"ycc_to_rgb_coef1": 0,
"ycc_to_rgb_coef2": 13802,
"ycc_to_rgb_coef3": 9574,
"ycc_to_rgb_coef4": -1540,
"ycc_to_rgb_coef5": -5348,
"ycc_to_rgb_coef6": 9574,
"ycc_to_rgb_coef7": 17610,
"ycc_to_rgb_coef8": 0,
"ycc_to_rgb_offset0": 16777216,
"ycc_to_rgb_offset1": 134217728,
"ycc_to_rgb_offset2": 134217728,
"rgb_to_lms_coef0": 7222,
"rgb_to_lms_coef1": 8771,
"rgb_to_lms_coef2": 390,
"rgb_to_lms_coef3": 2654,
"rgb_to_lms_coef4": 12430,
"rgb_to_lms_coef5": 1300,
"rgb_to_lms_coef6": 0,
"rgb_to_lms_coef7": 422,
"rgb_to_lms_coef8": 15962,
"signal_eotf": 65535,
"signal_eotf_param0": 0,
"signal_eotf_param1": 0,
"signal_eotf_param2": 0,
"signal_bit_depth": 12,
"signal_color_space": 0,
"signal_chroma_format": 0,
"signal_full_range_flag": 1,
"source_min_pq": 7,
"source_max_pq": 3079,
"source_diagonal": 42,
"num_ext_blocks": 3,
"ext_metadata_blocks": [
{
"Level1": {
"block_info": {
"ext_block_length": 5,
"ext_block_level": 1,
"remaining": [
0,
0,
0,
0
]
},
"min_pq": 0,
"max_pq": 0,
"avg_pq": 0
}
},
{
"Level5": {
"block_info": {
"ext_block_length": 7,
"ext_block_level": 5,
"remaining": [
0,
0,
0,
0
]
},
"active_area_left_offset": 0,
"active_area_right_offset": 0,
"active_area_top_offset": 276,
"active_area_bottom_offset": 277
}
},
{
"Level6": {
"block_info": {
"ext_block_length": 8,
"ext_block_level": 6,
"remaining": []
},
"max_display_mastering_luminance": 1000,
"min_display_mastering_luminance": 1,
"max_content_light_level": 596,
"max_frame_average_light_level": 200
}
}
]
},
"remaining": [
0,
0,
0,
0,
0
],
"rpu_data_crc32": 156245703
}
