Make "ASUS SBW-06D5H-U" UHD friendly?

Forum for discussions about UHD-capable dives
Post Reply
telefax.mousier-6p
Posts: 4
Joined: Thu Mar 13, 2025 4:19 pm

Make "ASUS SBW-06D5H-U" UHD friendly?

Post by telefax.mousier-6p »

Hello, I recently bought a blu ray drive and thought it can directly read 4k blu ray disks. It's pretty new, with an usb c port and cost like 100€ on amazon. Yesterday I found out that it can only read normal blu ray disks. Even though it's BDXL compatible which is very disappointing because it's new and not cheap.

So my question is if it's possible to flash the firmware to read 4k disks. I did some research and found that I can try to crossflash from BDR-US03 to BDR-US04. But I cannot find any firmware...

Here my info:

Code: Select all

Drive Information

Manufacturer: ASUS

Product: SBW-06D5H-U


Revision: E101


Serial number: xxx


Firmware date: 2018-08-22


Bus encryption flags: 1B


Highest AACS version: 68







LibreDrive Information





Status: Enabled






Drive platform: RS8511







Firmware name: PIONEER BDR-US03







Firmware type: Original (unpatched)








Firmware version: E101/ID26









DVD all regions: Yes









BD raw data read: Yes










BD raw metadata read: Yes










Unrestricted read speed: Yes
Coopervid
Posts: 2557
Joined: Tue Feb 19, 2019 10:32 pm

Re: Make "ASUS SBW-06D5H-U" UHD friendly?

Post by Coopervid »

telefax.mousier-6p wrote:
Fri Mar 14, 2025 6:18 pm
Hello, I recently bought a blu ray drive and thought it can directly read 4k blu ray disks. It's pretty new, with an usb c port and cost like 100€ on amazon. Yesterday I found out that it can only read normal blu ray disks. Even though it's BDXL compatible which is very disappointing because it's new and not cheap.

So my question is if it's possible to flash the firmware to read 4k disks. I did some research and found that I can try to crossflash from BDR-US03 to BDR-US04. But I cannot find any firmware...

Here my info:

Code: Select all

Drive Information

Manufacturer: ASUS

Product: SBW-06D5H-U


Revision: E101


Serial number: xxx


Firmware date: 2018-08-22


Bus encryption flags: 1B


Highest AACS version: 68







LibreDrive Information





Status: Enabled






Drive platform: RS8511







Firmware name: PIONEER BDR-US03







Firmware type: Original (unpatched)








Firmware version: E101/ID26









DVD all regions: Yes









BD raw data read: Yes










BD raw metadata read: Yes










Unrestricted read speed: Yes
PM sent.
telefax.mousier-6p
Posts: 4
Joined: Thu Mar 13, 2025 4:19 pm

Re: Make "ASUS SBW-06D5H-U" UHD friendly?

Post by telefax.mousier-6p »

Coopervid wrote:
Fri Mar 14, 2025 7:43 pm
telefax.mousier-6p wrote:
Fri Mar 14, 2025 6:18 pm
Hello, I recently bought a blu ray drive and thought it can directly read 4k blu ray disks. It's pretty new, with an usb c port and cost like 100€ on amazon. Yesterday I found out that it can only read normal blu ray disks. Even though it's BDXL compatible which is very disappointing because it's new and not cheap.

So my question is if it's possible to flash the firmware to read 4k disks. I did some research and found that I can try to crossflash from BDR-US03 to BDR-US04. But I cannot find any firmware...

Here my info:

Code: Select all

Drive Information

Manufacturer: ASUS

Product: SBW-06D5H-U


Revision: E101


Serial number: xxx


Firmware date: 2018-08-22


Bus encryption flags: 1B


Highest AACS version: 68







LibreDrive Information





Status: Enabled






Drive platform: RS8511







Firmware name: PIONEER BDR-US03







Firmware type: Original (unpatched)








Firmware version: E101/ID26









DVD all regions: Yes









BD raw data read: Yes










BD raw metadata read: Yes










Unrestricted read speed: Yes
PM sent.
Thank you very much. Crossflashing was straightforward and 4K disks are now readable! I got some issues with playing disks directly via VLC on macOS. I think it's not possible with this drive. But most important is that I don't need to buy another drive even though it's limited to 4x like in the UHD Disk Guide. But I think it's okay.

Is it possible to flash directly in macOS with Apple Silicon? If yes I could create a short manual.
telefax.mousier-6p
Posts: 4
Joined: Thu Mar 13, 2025 4:19 pm

Re: Make "ASUS SBW-06D5H-U" UHD friendly?

Post by telefax.mousier-6p »

This is my portable setup lol:
224D0BFD-9473-457E-ABE8-93877D3F0430 Medium.jpeg
224D0BFD-9473-457E-ABE8-93877D3F0430 Medium.jpeg (50.5 KiB) Viewed 429 times
Coopervid
Posts: 2557
Joined: Tue Feb 19, 2019 10:32 pm

Re: Make "ASUS SBW-06D5H-U" UHD friendly?

Post by Coopervid »

The firmware files are Windows only by the author. No options therefore.
GDZsobi
Posts: 1
Joined: Tue Mar 18, 2025 10:46 pm

Re: Make "ASUS SBW-06D5H-U" UHD friendly?

Post by GDZsobi »

I'm currently experiencing an issue similar to what is described in this post, my drive is unable to read 4K Blu-ray disk. It is the same model as mentioned in this post, but it has a newer firmware version, as I shown below.

Code: Select all

Drive Information
OS device name: E:
Manufacturer: ASUS
Product: SBW-06D5H-U
Revision: E102
Serial number: CIDL279490WL
Firmware date: 2023-04-20
Bus encryption flags: 1B
Highest AACS version: 76

LibreDrive Information
Status: Possible, not yet enabled
Drive platform: Pioneer RS8511
Firmware version: ID26
Is there a way to make my drive read 4K discs?

I'd appreciate any suggestion. Thank you for your help!
Coopervid
Posts: 2557
Joined: Tue Feb 19, 2019 10:32 pm

Re: Make "ASUS SBW-06D5H-U" UHD friendly?

Post by Coopervid »

GDZsobi wrote:
Wed Mar 26, 2025 9:31 am
I'm currently experiencing an issue similar to what is described in this post, my drive is unable to read 4K Blu-ray disk. It is the same model as mentioned in this post, but it has a newer firmware version, as I shown below.

Code: Select all

Drive Information
OS device name: E:
Manufacturer: ASUS
Product: SBW-06D5H-U
Revision: E102
Serial number: CIDL279490WL
Firmware date: 2023-04-20
Bus encryption flags: 1B
Highest AACS version: 76

LibreDrive Information
Status: Possible, not yet enabled
Drive platform: Pioneer RS8511
Firmware version: ID26
Is there a way to make my drive read 4K discs?

I'd appreciate any suggestion. Thank you for your help!
You are out of luck with firmware newer than Dec. 2022.
