OS device name: /dev/rdisk5
Current profile: BD-ROM
Manufacturer: HL-DT-ST
Product: BD-RE BU40N
Revision: 1.02
Serial number:
Firmware date: 2120-12-01 17:16
Bus encryption flags: 1F
Highest AACS version: 76
LibreDrive Information
Status: Possible (with patched firmware)
Drive platform: MT1959
Harware support: Yes
Firmware support: No
Firmware type: Original (patched version available)
Firmware version: 1.02
Enclosure is the Archgon MD-8017-U3. Mac System Profiler reports it as the following:
MD-810x:
Product ID: 0x3910
Vendor ID: 0x13fd (Initio Corporation)
Version: 2.17
Serial Number: 30303030303030303030303030303030
Speed: Up to 480 Mb/sec
Manufacturer: Archgon
I followed the instructions for mac, but at the end, the firmware is still reporting the drive is 1.02 even after the command line tool said it successfully updated.
Code: Select all
[MakeMKV.app/contents/macos] wallace% ./makemkvcon f -d '/IOBDServices/E3C16F37' -f /Users/wallace/Downloads/sdf.bin rawflash main -i /Users/wallace/Downloads/HL-DT-ST-BD-RE_BU40N-1.03-NM00000-211810241934.bin
Reading input file /Users/wallace/Downloads/HL-DT-ST-BD-RE_BU40N-1.03-NM00000-211810241934.bin
Flashing flags = 0x0 : 0 0 0 0 : ---- ---- ---- ----
Current Drive ID: HL-DT-ST_BD-RE_BU40N_1.02_212012011716_MO1LC2B2038
Ready to write drive flash memory.
Type "yes" to continue, "no" to abort
yes
Operation started: Sending flash image to drive
100% Operation finished
Operation started: Programming flash
100% Operation finished
Done successfully
[MakeMKV.app/contents/macos] wallace% ./makemkvcon f -l
Found 2 drives(s)
00: /IODVDServices/737CDE29
HL-DT-ST_DVDRW__GA32N_KE06_K0DBCF13116
01: /IOBDServices/E3C16F37
HL-DT-ST_BD-RE_BU40N_1.02_212012011716_MO1LC2B2038
